10.4 “resistance touch screen glass custom 5 wire 4 wire commercial panel accessories
Product Introduction
This product is a 10.4-inch resistive touch screen, which is a panel accessory for the display. This product has the characteristics of durability, long life, and cheap price.
First of all, one of the characteristics of this 10.4-inch resistive touch house is its durability, because most of its construction is made of high-quality materials, so it is not easy to damage during use. Secondly, the service life of the resistive screen is also longer, and it can usually be used for a few years to ten years or even longer.
In addition, the price of this 10.4-inch resistive touch screen instrument is very affordable. Compared with other touch screen products, its price is more favorable and can meet the needs of customers.
Product Characteristics
Second, let's take a look at the construction of a resistive touch screen. It consists of two resistive films that create resistance when a finger or other object touches the screen, sensing the position of the point of contact. The screen has high accuracy when touched by a finger, and is very sensitive, able to respond to the slightest touch of the user.
All in all, this 10.4-inch resistive touchscreen instrument is a very cost-effective screen accessory. It has multiple characteristics such as durability, long life, and cheap price, and can meet the needs of users. If you are looking for a 10.4-inch resistive touch screen instrument, this product will be a good choice
Product Specification
Ruixiang touch display technology Co., Ltd.
Resistive Touch Screen
OEM/ODM customization is supported.
The following are not all sizes. If the size you need is not in the list, please tell us the size you need.
| Size (inch) |
Part No. | TP O.D (mm) |
TP A.A (mm) |
Lenth of FPC (mm) |
Total T (mm) |
Remark | |
| 1.7 | RXA-017003-01 | 33.4*44.3 | 29.03*36.04 | 9 | 1.15 | Contact US | |
| RXA017004-01 | 34.4*46.3 | 28.43*35.44 | 12.35 | 1.15 | |||
| RXA017005-01 | 33.63*43.22 | 28.03*35.04 | 9.6 | 1.15 | |||
| 2 | RXA020002-02 | 35.4*46.75 | 31.24*41.27 | 11.2 | 1.2 | ||
| 2.2 | RXA022001-01 | 38.3*53.69 | 34.84*46.12 | 27.82 | 1.2 | ||
| RXA022002-01 | 49.1*40.6 | 44.1*33.22 | 25.3 | 1.2 | |||
| 2.4 | RXA024001-01 | 42.32*59.86 | 35.72*47.96 | 11.2 | 1.2 | ||
| RXA024002-01 | 41.82*58.04 | 38.92*50.46 | 12.5 | 1.2 | |||
| RXA024005-01 | 42.32*59.86 | 37.32*53.16 | 7.72 | 1.2 | |||
| RXA024020-01 | 37.28*49.1 | 32.68*40.6 | 9.4 | 1.2 | |||
| 2.6 | RXA026001-01 | 45.7*63.5 | 40.6*57.45 | 7.62 | 1.25 | ||
| 2.8 | RXA028001-02 | 42.7*74 | 37.72*62.7 | 10.3 | 1.15 | Contact US | |
| RXA028004-01 | 49.4*68.8 | 44.1*58.15 | 13.3 | 1.2 | |||
| RXA028012-01 | 49.8*69 | 44.2*58.6 | 12.5 | 1.25 | |||
| 2.9 | RXA028030-01 | 51.6*69.8 | 46.5*61.5 | 50 | 1.45 | ||
| 3 | RXA030008-01 | 44.5*76.3 | 40.5*66.5 | 12.7 | 1.15 | ||
| RXA030009-01 | 51.4*70.2 | 44.9*60.2 | 28.8 | 1.15 | |||
| 3.2 | RXA032007-01 | 51.2*78.2 | 45.64*67.96 | 16.35 | 1.2 | ||
| RXA032011-01 | 55.74*77.4 | 50.2*66.4 | 15.85 | 1.2 | |||
| 3.5 | RXA035003-01 | 60.95*83 | 52.4*73.2 | 24.8 | 1.45 | ||
| RXA035004-01 | 76.5*63.5 | 70.48*52.96 | 17.7 | 1.2 | |||
| 4 | RXA040001-01 | 56.74*96.3 | 52.44*87 | 12.73 | 1.1 | ||
| RXA040011-01 | 65.6*104.5 | 54.8*92.3 | 21.7 | 1.15 | Contact US | ||
| 4.3 | RXA043001-01 | 104.8*65 | 98.3*56.6 | 25 | 1.15 | ||
| RXA043002-01 | 102*63.5 | 95.84*54.66 | 25 | 1.2 | |||
| 4.5 | RXA045002-01 | 65.5*108.5 | 54.86*96 | 19.28 | 1.2 | ||
| RXA045003-01 | 63.5*111 | 56.04*99.237 | 23.15 | 1.15 | |||
| 4.6 | RXA046001-01 | 62.8*112.5 | 55.6*100.48 | 50 | 1.2 | ||
| 4.7 | RXA047003-01 | 63*112.5 | 58.2*103.08 | 11.1 | 1.2 | ||
| 4.8 | RXA048004-01 | 109*72.1 | 94.74*53.86 | 23 | 1.45 | ||
| 5 | RXA050001-01 | 120*73.5 | 110.7*62.5 | 28 | 1.2 | ||
| RXA050002-01 | 119.8*73 | 108.8*65.6 | 28 | 1.2 | |||
| RXA050003-01 | 117.5*70.2 | 111.88*63.83 | 28.4 | 1.2 | |||
| RXA050026-01 | 66.3*121 | 62.7*110.8 | 50 | 1.4 | |||
| 5.6 | RXA-056001-01 | 126.5*100 | 110.9*82.7 | 79.7 | 1.4 | Contact US | |
| RXA-056002-01 | 128*79 | 108*65.5 | 25.5 | 1.45 | |||
| RXA-056011-01 | 126.35*99.85 | 114.28*85.71 | 38.1 | 2.2 | |||
| 5.7 | RXA-057002-01 | 128*98.2 | 115.2*86.4 | 39 | 2.2 | ||
| RXA-057007-01 | 101.5*129.1 | 86.4*115.2 | 70 | 1.4 | |||
| RXA-057007-01 | 129.1*101.7 | 115.20*86.4 | 43 | 1.49 | |||
| 6.1 | RXA-061004-01 | 104.7*132.5 | 87.38*116.18 | 80 | 1.48 | ||
| 6.5 | RXA-065005-01 | 154.85*89 | 145*78.4 | 50.2 | 1.4 | ||
| 7 | RXA-070001-01 | 163*97 | 154.40*88.80 | 30.3 | 1.2 | Flug FPC | |
| RXA-070003-01 | 163.5*98.5 | 154.08*85.92 | 61 | 1.4 | |||
| RXA-070004-01 | 161.9*94.5 | 153.68*85.52 | 50 | 1.45 | |||
| RXA-070007-01 | 161*96.5 | 154*87.1 | 30 | 1.4 | |||
| RXA-070010-01 | 164.3*99.30 | 152.0*84.50 | 55.5 | 1.45 | Contact US | ||
| RXA-070108-01 | 99.8*161 | 94.5*151 | 50 | 1.5 | |||
| 7.5 | RXA-075013-01 | 164*103 | 157*91.5 | 84.5 | 1.1 | ||
| 8 | RXA-080001-01 | 192.8*116.5 | 175.2*99.36 | 79.5 | 1.4 | ||
| RXA-080010-01 | 191.2*115.3 | 176.64*99.36 | 62.47 | 1.5 | |||
| RXA-080014-01 | 182*140 | 163.4*122.4 | 89 | 1.4 | |||
| 9 | RXA-090001-01 | 210.2*126.3 | 194.9*109.4 | 98 | 1.45 | ||
| 10.1 | RXA-101001-01 | 229.17*148.8 | 217.06*135.7 | 98 | 1.4 | ||
| RXA-101004-01 | 234.2*148.7 | 220.8*130.5 | 79.5 | 1.5 | |||
| RXA-101013-01 | 233.8*148.4 | 221.2*130.5 | 80 | 1.53 | |||
| RXA-101027-01 | 145.8*235 | 125.3*220.8 | 80 | 1.5 | |||
| RXA-101038-01 | 234.5*142 | 223.72*126.28 | 50.5 | 1.5 | |||
| 10.2 | RXA-102001-01 | 234.5*145.3 | 221.4*132.5 | 57.5 | 1.4 | Contact US | |
| 10.4 | RXA-104002-01 | 225*172 | 211.8*159 | 88 | 1.5 | ||
| RXA-104003-01 | 224.5*172 | 212.2*159.4 | 50 | 1.4 | |||
| RXA-104013-01 | 230.4*179.8 | 212.2*159.4 | 100 | 2.2 | |||
| 12.1 | RXF-12003-01 | 265*208.99 | 245.98*184.48 | 135.9 | 2 | 5 wire | |
| RXH-12004-01 | 278.2*211.2 | 245.5*184 | 127.5 | 5.3 | 5 wire | ||
| 15 | RXH-15006-01 | 332.9*248.9 | 307*230.5 | 355 | 3.4 | 5 wire | |
| RXH-15007-01 | 322*247 | 304*228 | 108 | 2.3 | 5 wire | ||
| 15 | RXA-15003-01 | 322*247 | 304*228 | ||||
| RXA-150002-01 | 322*247 | 302*226 | 87.85 | 2.3 | |||
| RXA-150008-01 | 325*252 | 305.13*229.07 | 81.02 | 2.2 |
